pH Sensor Pure Water pHure Anlg
Convenient Measurement in Pure Waters.The pHure sensor with an internally-pressurized gel reference system delivers ease of use to simplify pH monitoring in low conductivity water.
High Dependability in Low Conductivity
The pHure sensor with pressurized gel electrolyte design delivers convenience with highly accurate pH measurements for pure water applications.
Fast Response Time
This pH sensor, when combined with a low volume housing to prevent particle accumulation, ensures a fast, reliable response time.
High Measurement Stability
This sensor's controlled sample flow path ensures a fast response, preventing corrosion particles from accumulating around the electrode membrane.
Material No.: 52002447
Features
Reliable Low Conductivity Measurement
Designed to excel in challenging conditions, pHure sensors deliver highly accurate pH measurement in pure waters. Stability of the reference diaphragm/junction potential provides monitoring consistency in low conductivity applications.
Faster Response, Simplified Maintenance
With a special glass membrane and an integrated temperature sensor, the pHure sensor ensures a fast, reliable response. Prioritize convenience by extending lifetime and minimizing maintenance with the internally pressurized gel electrolyte.
High Measurement Stability
The pHure sensor’s controlled sample flow path with minimum volume reduces the accumulation of corrosion particles around the electrode membrane. A sealed stainless steel housing prevents contamination from air and provides electrical shielding.
Specifications
Specifications - pH Sensor Pure Water pHure Anlg
| Process Connection | ¼" NPT(F) in/ out |
| Operating Temperature (Celsius) | 0 °C - 80 °C |
| Operating Temperature (Fahrenheit) | 32 °F - 176 °F |
| Sample Flow rate | 50 to 150 ml/min |
| Sample Conductivity > (μS/cm) | 1.5 |
| Refillable Electrolyte | No |
| pH Range | 1 – 11 |
| Sterilizable/Autoclavable | No |
| Sensor Length | 120 mm |
| Cable Connector | VP |
| Operating Pressure (Bar) | 0-7 barg @ 100 °C |
| Model Family | pHure |
| Other certificates | CE |
| pH Sensing Technology | Glass Membrane Suitable For Low Temperatures (LoT) |
| Reference System | Gel Electrolyte |
| Temperature Sensor | PT 1000 |
| Hazardous Area Approvals | No |
| ISM (Digital) or Analog | Analog |
| Measurement Parameter | pH |
| Primary Media/Application | Other Water Processes Power Plant Water/Steam Semiconductor Water |
| Shaft Material | Glass |
| Hygienic/Biocompatibility Approvals | No |
| Operating Pressure (PSI) | 0-101 psig @ 212 °F |
Documentation
Datasheets
Accurate, continuous pure water monitoring can reduce expensive unplanned maintenance, downtime and capital equipment expenditure. The pHure Sensor w...
Accessories
Sensor Calibration & Maintenance Tools
Consumables
Buffers for In-Line pH Sensors
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This single bottle contains 250 mL of pH 4.01 buffer solution.
Material No.: 51340057
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This single bottle contains 250 mL of pH 7.00 buffer solution.
Material No.: 51340059
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This single bottle contains 250 mL of pH 9.21 buffer solution.
Material No.: 51300193
Certified and traceable pH buffer solution for sensor calibration and verification in life science and industrial applications. This single bottle contains 250 mL of pH 10.00 buffer solution.
Material No.: 51340056
